CNRM HDTM rope machine
CNRM HDTM combined strander and rope-layer
For production of finished coiled rope from natural and synthetic fiber yarns
Three-strand and four-strand models
From start to finish in one continuous operation
Extremely high output
Performance & advantages
· High productivity
· Sprocket drive
· Rigid construction
· Direct coiling head winding
· With digital length counter meter
· Auto stop after yarn breakage to control wastage
· Door sensor, protective door with steel wire mesh
· Low noise level, Low maintenance, easy operation system
· Surface of parts are bluing and with plating treatment
· Thermal refining for shaft parts, quenching treatment for gear and sprocket wheel
HDTM-M33
Technical data
Rope range: | Φ3-10mm | |
Lay range: | 15-38mm | |
Rope lay: | S or Z | |
Take-up, coiling head: | Φ480mm, traverse 265mm, barrel Φ138mm | |
Take-up, max. Weight: | Polypropylene 25kg | |
Pay-off packages | M33-3 | M33-4 |
3x8 , max.Φ175X300mm traverse | 4X8,max.Φ175X300 mm traverse | |
3x6 , max.Φ225X300mm traverse | 4X6,max.Φ225X300 mm traverse | |
Take-up capacity | Production capacity | |||
Coiling head | Output(24 hours) | |||
Φ4mm | 3572m | Φ4mm | 140kg | |
Φ6mm | 1563m | Φ6mm | 472kg | |
Φ8mm | 926m | Φ8mm | 1118kg | |
Φ10mm | 595m | Φ10mm | 2185kg | |
Examples based on three -strand polypropylene rope. Lay length: medium. Efficiency rate: 100%. 24 hour’s production
